商品信息

基本参数

品牌：	未填
所在地：	上海
起订：	≥1 个
供货总量：	1000 个
有效期至：	长期有效
额定电流：	5-30
额定电压：	12

详细说明

额定电流	5-30
额定电压	12
应用范围	中间
品牌	德国海拉
型号	4RD 960 388-691

*************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************

HELLARelay, main current

4RD 933 332-011

Relay, main current

Capacity at 12V: 20/40A, Supplementary Article/Supplementary Info: with holder, Colour: Black, Inductive Load: 20 A, 6 A, Capacitive Load: 10 A, 20 A, Rated Voltage: 12 V, Ohmic Load: 20 A, 40 A, Number of Poles: 5, Wiring Diagramme: W1, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, Plug-type ID: B1, Temp. Range: 80 °C

4RD 933 332-021

Relay, main current

Supersedes: 4RD 003 520-251

Supplementary Article/Supplementary Info 2: with diode, Capacity at 12V: 20/30A, Supplementary Article/Supplementary Info: without holder, Colour: Green, Inductive Load: 20 A, 6 A, Capacitive Load: 10 A, 20 A, Rated Voltage: 12 V, Ohmic Load: 20 A, 30 A, Number of Poles: 5, Wiring Diagramme: W3, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, Plug-type ID: B1, Temp. Range: 80 °C

4RD 933 332-027

Relay, main current

Supersedes: 4RD 003 520-257

Supplementary Article/Supplementary Info 2: with diode, Capacity at 12V: 20/30A, Supplementary Article/Supplementary Info: without holder, Colour: Green, Inductive Load: 20 A, 6 A, Capacitive Load: 10 A, 20 A, Quantity: 40, Rated Voltage: 12 V, Ohmic Load: 20 A, 30 A, Number of Poles: 5, Wiring Diagramme: W3, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, Plug-type ID: B1, Temp. Range: 80 °C

4RD 933 332-031

Relay, main current

Supersedes: 4RD 960 388-691

Supplementary Article/Supplementary Info 2: with resistance, Capacity at 12V: 20/30A, Supplementary Article/Supplementary Info: with holder, Waterproof, Colour: Black, Inductive Load: 20 A, 6 A, Capacitive Load: 10 A, 20 A, Rated Voltage: 12 V, Ohmic Load: 20 A, 30 A, Number of Poles: 5, Wiring Diagramme: W2, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, 6K7 / 6K9K, Plug-type ID: B1, Temp. Range: 80 °C

4RD 933 332-041

Relay, main current

Supersedes: 4RD 003 520-081 , 4RD 003 520-082

Capacity at 12V: 20/30A, Supplementary Article/Supplementary Info: with holder, Colour: Black, Inductive Load: 20 A, 6 A, Capacitive Load: 10 A, 20 A, Rated Voltage: 12 V, Ohmic Load: 20 A, 30 A, Number of Poles: 5, Wiring Diagramme: W1, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, Plug-type ID: B1, Temp. Range: 80 °C

4RD 933 332-047

Relay, main current

Supersedes: 4RD 003 520-082

Capacity at 12V: 20/30A, Supplementary Article/Supplementary Info: with holder, Colour: Black, Inductive Load: 20 A, 6 A, Capacitive Load: 10 A, 20 A, Quantity: 40, Rated Voltage: 12 V, Ohmic Load: 20 A, 30 A, Number of Poles: 5, Wiring Diagramme: W1, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, Plug-type ID: B1, Temp. Range: 80 °C

4RD 933 332-051

Relay, main current

Supersedes: 4RD 003 520-131 , 4RD 003 520-132

Capacity at 12V: 20/40A, Supplementary Article/Supplementary Info: without holder, Colour: Black, Inductive Load: 20 A, 6 A, Capacitive Load: 10 A, 20 A, Rated Voltage: 12 V, Ohmic Load: 20 A, 40 A, Number of Poles: 5, Wiring Diagramme: W1, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, Plug-type ID: B1, Temp. Range: 80 °C

4RD 933 332-057

Relay, main current

Supersedes: 4RD 003 520-137

Capacity at 12V: 20/40A, Supplementary Article/Supplementary Info: without holder, Colour: Black, Inductive Load: 20 A, 6 A, Capacitive Load: 10 A, 20 A, Quantity: 40, Rated Voltage: 12 V, Ohmic Load: 20 A, 40 A, Number of Poles: 5, Wiring Diagramme: W1, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, Plug-type ID: B1, Temp. Range: 80 °C

4RD 933 332-061

Relay, main current

Supersedes: 4RD 003 520-091 , 4RD 003 520-093

Capacity at 24V: 10/20A, Supplementary Article/Supplementary Info: with holder, Colour: Black, Inductive Load: 16 A, 8 A, Capacitive Load: 15 A, 5 A, Rated Voltage: 24 V, Ohmic Load: 10 A, 20 A, Number of Poles: 5, Wiring Diagramme: W1, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, Plug-type ID: B1, Temp. Range: 80 °C

4RD 933 332-067

Relay, main current

Supersedes: 4RD 003 520-097

Capacity at 24V: 10/20A, Supplementary Article/Supplementary Info: with holder, Colour: Black, Inductive Load: 16 A, 8 A, Capacitive Load: 15 A, 5 A, Quantity: 40, Rated Voltage: 24 V, Ohmic Load: 10 A, 20 A, Number of Poles: 5, Wiring Diagramme: W1, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, Plug-type ID: B1, Temp. Range: 80 °C

4RD 933 332-071

Relay, main current

Supersedes: 4RD 003 520-031 , 4RD 003 520-071 , 4RD 003 520-072

Capacity at 24V: 10/20A, Supplementary Article/Supplementary Info: without holder, Colour: Black, Inductive Load: 16 A, 8 A, Capacitive Load: 15 A, 5 A, Rated Voltage: 24 V, Ohmic Load: 10 A, 20 A, Number of Poles: 5, Wiring Diagramme: W1, Combi Switch Function: Opener, Lock, Directional Contact, Prot.type (IP Code): 54, Plug-type ID: B1, Temp. Range: 80 °C
